ZLP1000 Electric Window Cleaning Hoist Rope Suspended

Advanced Rotating Lift

Tarehe 21 Mei, 2017

Jukwaa Lililosimamishwa

Advanced Rotating Lift

Advanced Rotating Lift is a temporary powered access configuration for facade construction, cleaning, painting or maintenance. Platform length, rated load, voltage, hoist model, wire ropes and roof suspension conditions should be confirmed for the actual project.

Advanced rotating lift table
Image of Advanced rotating lift table

Maelezo ya Haraka:

  • Mahali pa asili: Shanghai, Uchina (Bara)
  • Jina la Biashara: Mafanikio
  • Nambari ya Mfano:ZLP250,ZLP500,ZLP630,ZLP800,ZLP1000
  • Huduma ya Baada ya Uuzaji Imetolewa: Wahandisi wanaopatikana kwa huduma za mashine nje ya nchi
  • Name:rotating lift table
  • Rangi: hiari
  • Ugavi wa umeme (V):220,380,415,440
  • Kifaa cha Usalama:kipengee 7
  • Nyenzo: chuma au alumini
  • Matibabu ya uso: Kunyunyizia rangi au mabati ya dip-moto
  • Sehemu ya Bure: usambazaji
  • kamba ya chuma: mabati ya kuzamisha moto
  • Pandisha: Imetengenezwa kwa alumini ya kutupwa
  • Cheti:CE,ISO9001-2008

Video inayohusiana:

Maelezo:

Advanced rotating lift table
Advanced rotating lift table

Onyesha Vifaa Vinavyohusiana:

Advanced rotating lift table Related Accessories Show
Advanced rotating lift table Related Accessories Show

Acha ujumbe:

Unaweza pia kupenda:

  • Advanced Rotating Lift - image 6

    anti-tilted zlp630 suspended platform

    • Mahali pa asili: Shanghai, Uchina (Bara)
    • Jina la Biashara: Mafanikio
    • Nambari ya mfano: ZLP630
    • Pandisha:LTD63
    • Jukwaa: 6 * 0.69m
    • kamba ya waya:4*31w+NF-8.3
    • Kufuli ya usalama: isiyo na tilted
    • Uzito uliopimwa: 630kg
    • urefu wa kufanya kazi: 100 m
    • Nyundo nzito: 10kg kwa vipande
    • Zege kukabiliana na uzito: 25kg / kipande
    • Hali:100% Mpya
    • Ugavi wa Nguvu:380V/50Hz
    Export to: Allahabad, Depok, Lucknow etc.
    Related Keywords: Zlp630 Suspended Access Platform in Allahabad, Suspended Platform

    Acha ujumbe

  • Advanced Rotating Lift - image 7

    chimney suspended access platform (CE) factory

    • Mahali pa asili: Shanghai, Uchina (Bara)
    • Jina la Biashara: Mafanikio
    • Nambari ya mfano: ZLP630
    • Nyenzo: Chuma au Aloi
    • Nguvu ya Kuinua: 380v/50 HZ
    • Kasi ya kuinua: 8-10m / min
    • Uzito wa kukabiliana: 800-1000kg
    • Urefu wa Juu wa Kuinua: 200m
    • Uzito uliopimwa: 250-1000 kg
    • Kebo:100m
    • Nguzo ya boriti ya mbele: 1.3-1.5m
    • Urefu wa kuinua: 100 m
    Export to: Russia, Yemen etc.
    Related Keywords: Lifting Rope Suspended Platform in Depok, Suspended Platform For Paint Coatings in Lucknow

    Acha ujumbe

  • Advanced Rotating Lift - image 8

    High building construction cleaning platform motor lift hanging gondola

    • Mahali pa asili: Shanghai, Uchina (Bara)
    • Jina la Biashara: Mafanikio
    • Nambari ya Mfano: ZLP250 ZLP500 ZLP630 ZLP800 ZLP1000
    • Rated load:1000kg
    • Kasi ya kuinua:8~10m/min
    • Urefu wa kuinua: 100 m
    • Kebo:100m
    • Uzito wa kukabiliana: 1000kg
    Export to: Iran, Kharkiv, Netherlands, Allahabad etc.
    Related Keywords: Working Towers Platforms in Russia, Economical Rope Suspended Platform in Yemen

    Acha ujumbe

  • Advanced Rotating Lift - image 9

    Success ZLP800 Powered swing stage facade cleaning suspended platform for construction

    • Mahali pa asili: Shanghai, Uchina (Bara)
    • Jina la Biashara: Mafanikio
    • Nambari ya Mfano: ZLP500/630/800/1000
    • Uwezo wa kupakia: 500kgs;630kgs;800kgs;1000kgs
    • Nyenzo: Chuma cha Mabati/Alumini
    • Matibabu ya uso:Mabati;HDG au kunyunyuzia kwa plastiki
    • Urefu wa Jukwaa:2m-12m;OEM
    • Nguvu ya Magari ya Umeme: 1.5KW*2; 1.8KW*2; 2.2KW*2;3.0KW*2
    • Voltage:380V/50HZ/AWAMU TATU 220V/50HZ/AWAMU MOJA
    • MAX Urefu wa kuinua: 200M
    • Rangi: Bluu, machungwa, nyekundu, fedha au umeboreshwa
    • Maombi: Ujenzi wa Jengo; Uchoraji, kusafisha madirisha
    • Udhibitisho: ISO9001/CE/TUV
    Export to: Chicago, Luanda, Netherlands, Iran etc.
    Related Keywords: Suspended Platform, Economical Rope Suspended Platform in Yemen

    Acha ujumbe

  • Advanced Rotating Lift - image 10

    ZLP Portable Swing Stage / Suspended Platform (CE)

    • Mahali pa asili: Shanghai, Uchina (Bara)
    • Jina la Biashara: Mafanikio
    • Nambari ya Mfano: ZLP500
    • Huduma ya Baada ya Uuzaji Imetolewa: Wahandisi wanaopatikana kwa huduma za mashine nje ya nchi
    • Nyenzo: Chuma, Aloi ya Alumini
    • Rangi: Nyekundu, Njano, Bluu, nk
    • Matibabu ya uso:Kupaka poda, mabati ya moto
    • Urefu: 2m, 2.5m, 3m, 5m, 6m, 7.5m, nk.
    • Nguvu: 1.5kw, 1.8kw, 2kw
    • Uwezo wa Upakiaji uliokadiriwa: 150kg, 250kg, 500kg, 630kg, 800kg, 1000kg
    • Voltage:ZLP Portable Swing Stage / Suspended Platform accept different voltage
    • Maombi:Jengo la juu, tanki kubwa, Chimney, Mabwawa, Madaraja, Derrick, nk
    • Jukwaa maalum: Inaweza kubinafsishwa na kutolewa
    • Uthibitisho: ISO, CE
    Export to: Allahabad, Lucknow, Yemen, Kharkiv etc.
    Related Keywords: Zlp630 Suspended Access Platform in Allahabad, Working Towers Platforms in Russia

    Acha ujumbe

Project Information Required

  • Building height and required platform length
  • Workers, tools and material load
  • Voltage, phase and frequency
  • Roof parapet, suspension beam and counterweight conditions

Browse the suspended platform article library or review more ZLP gondola configurations. Installation and operation should follow the approved system and applicable OSHA suspended scaffold requirements.
